Hardware reference
A model-by-model look at published Geotab hardware details, with direct links to the manufacturer's specifications.
These are references to Geotab hardware, not confirmation that EveryTrack supplies any listed model or that every feature is available through EveryTrack. Compatibility, installation, recording and data access depend on the fitted equipment, vehicle and configuration. No model here is assigned to an EveryTrack plan.
01 / Cameras
GO Focus, GO Focus Plus and GO Focus Pro are separate camera families. The Plus and Pro each have distinct dual-camera and road-only configurations.
Forward-facing camera
| View | Forward-facing |
|---|---|
| Dimensions | 130 × 66.9 × 49.4 mm |
| Weight | 294 g |
| Vehicle power | 12 V / 24 V |
| Connectivity | LTE Cat 1; bands vary by regional model |
| Operating range | −30 °C to +60 °C |
Geotab does not state a resolution, field of view or storage capacity on this technical-specification page.
Official Geotab specifications for GO Focus (opens in a new tab)Road and cabin camera
| Road-facing | 1080p · 142° diagonal / 116° horizontal / 60° vertical |
|---|---|
| Cabin-facing | 720p · 940 nm infrared illuminator |
| Dimensions | 123 × 106 × 45 mm |
| Weight | 213 g |
| Vehicle power | 12 V / 24 V |
| Connectivity | Wi‑Fi 5, Bluetooth 4.2 BLE, LTE Cat 6, GNSS |
| Storage | 128 GB microSDXC supplied; 512 GB and 1 TB options |
Road camera without cabin-facing lens
| Road-facing | 1080p · 142° diagonal / 116° horizontal / 60° vertical |
|---|---|
| Cabin-facing | Not fitted |
| Dimensions | 98 × 106 × 45 mm |
| Weight | 193 g |
| Vehicle power | 12 V / 24 V |
| Connectivity | Wi‑Fi 5, Bluetooth 4.2 BLE, LTE Cat 6, GNSS |
| Storage | 128 GB microSDXC supplied; 512 GB and 1 TB options |
Road and cabin camera with optional auxiliary inputs
| Road-facing | 1080p · 143° diagonal / 120° horizontal / 64° vertical |
|---|---|
| Cabin-facing | 1080p · 143° diagonal / 120° horizontal / 64° vertical; 940 nm infrared |
| Dimensions | 124 × 88.6 × 101 mm |
| Weight | 340 g |
| Vehicle power | 12 V / 24 V |
| Connectivity | Wi‑Fi 2.4/5 GHz, Bluetooth 5.0 BLE, LTE Cat 4, GNSS |
| Storage | 128 GB microSDXC supplied; optional cards in two slots, up to 2 TB total |
Some auxiliary camera accessories in Geotab's documentation are marked coming soon; availability should be confirmed with Geotab.
Official Geotab specifications for GO Focus Pro — Dual Camera (opens in a new tab)Road camera without cabin-facing lens
| Road-facing | 1080p · 143° diagonal / 120° horizontal / 64° vertical |
|---|---|
| Cabin-facing | Not fitted |
| Dimensions | 124 × 88.6 × 72 mm |
| Weight | 300 g |
| Vehicle power | 12 V / 24 V |
| Connectivity | Wi‑Fi 2.4/5 GHz, Bluetooth 5.0 BLE, LTE Cat 4, GNSS |
| Storage | 128 GB microSDXC supplied; optional cards in two slots, up to 2 TB total |
Some auxiliary camera accessories in Geotab's documentation are marked coming soon; availability should be confirmed with Geotab.
Official Geotab specifications for GO Focus Pro — Road-Only (opens in a new tab)Optional auxiliary cameras are documented for GO Focus Plus and GO Focus Pro, but accessory specifications and availability depend on the chosen configuration. See the official product pages for actual product photography.
See Geotab's camera range and product photos02 / Vehicle trackers
GO9, GO9+ and GO9 RUGGED differ in size, installation and connectivity. Network capabilities can vary between regional models and hardware revisions.
Plug-in vehicle tracker
| Dimensions | 75 × 50 × 23 mm |
|---|---|
| Weight | 70 g |
| Vehicle power | 12 V / 24 V |
| Positioning | GNSS; constellation support varies by hardware revision |
| Connectivity | Cellular bands and network type vary by regional SKU |
| Operating range | −40 °C to +85 °C |
Plug-in vehicle tracker with expanded connectivity
| Dimensions | 77.3 × 53 × 27.5 mm |
|---|---|
| Weight | 97 g |
| Vehicle power | 12 V / 24 V |
| Positioning | GPS, GLONASS, BeiDou and Galileo |
| Connectivity | LTE Cat 4; Wi‑Fi hotspot on supported SKUs |
| Operating range | −40 °C to +85 °C |
The GP9-LTETENG variant does not include the Wi‑Fi hotspot. Network bands vary by SKU.
Official Geotab specifications for GO9+ (opens in a new tab)Hard-wired tracker for exposed installations
| Dimensions | 159 × 122 × 31 mm casing; 1,000 mm cable |
|---|---|
| Weight | 396 g |
| Vehicle power | 12 V / 24 V |
| Positioning | GPS and GLONASS |
| Protection | IP6X dust, IPX8 immersion and IPX9K spray |
| Connectivity | Cellular support varies by regional SKU |
Asset trackers such as GO Anywhere are a separate product category and are not included in this vehicle-device comparison.
See Geotab's product range and photosTracking, cameras, diagnostics and driver visibility that sit alongside the driving-school software you already use.
